COMPONENTS

RE-ASSEMBLY 1. Keep the temporary lug nuts in place while the rear caliper and pads are re-installed. Once the rear wheels are back on the car and you're able to test the brakes, it has been recommended that you burn in the parking brake by driving with the parking brake depressed for about 1/4 mile. RE-36 BODY PANEL REPLACEMENT REAR FLOOR SIDE MEMBER (ASSY) REMOVAL Before removing the rear floor side member, remove the rear floor pan. Page 60 BODY PANEL REPLACEMENT RE-37 INSTALLATION Temporarily install the new part and measure each part in accordance with the body dimen- sion diagram.

OVERHAUL

HINT:

• Use the same procedures for the RH side and LH side.
• The procedures listed below are for the LH side.

1. REMOVE REAR WHEEL

2. SEPARATE REAR DISC BRAKE CALIPER ASSY LH

(a) Remove the 2 bolts and separate the rear disc brake caliper assy LH.

HINT: Do not disconnect the flexible hose from the disc brake caliper assy LH.

3. REMOVE REAR DISC

(a) Release the parking brake, and remove the rear disc.

HINT: If the disc cannot be removed easily, turn the shoe adjuster until the wheel turns freely.

(b) Place machmarks on the rear disc and the axle hub.

(c) Remove the rear disc.

4. INSPECT BRAKE DISC INSIDE DIAMETER

(a) Using a brake drum gauge or equivalent tool, measure the inside diameter of the rear disc.

Standard inside diameter: 190 mm (7.480 in.) Maximum inside diameter: 191 mm (7.520 in.)

If the inside diameter exceeds the maximum, replace the brake disc.

5. REMOVE PARKING BRAKE SHOE RETURN TENSION SPRING

(a) Using needle-nose pliers, remove the 2 parking brake shoe return tension springs No.1.

6. REMOVE PARKING BRAKE SHOE STRUT LH

(a) Remove the parking brake shoe strut LH and the parking brake shoe strut compression spring.

7. REMOVE PARKING BRAKE SHOE ASSY LH NO.1

(a) Remove the parking brake shoe hold down spring cup No.1, parking brake shoe hold down spring and parking brake shoe hold down spring cup No.2.

(b) FF: Remove the parking brake shoe hold down spring pin No.1.

(c) Disconnect the parking brake shoe return spring No.2 and remove the parking brake shoe assy LH No.1.

8. REMOVE PARKING BRAKE SHOE ADJUSTING SCREW SET

(a) Remove the parking brake shoe adjusting screw set.

(b) Remove the parking brake shoe return tension spring No.2.

9. REMOVE PARKING BRAKE SHOE ASSY LH NO.2

(a) Remove the parking brake shoe hold down spring cup No.1, parking brake shoe hold down spring, parking brake shoe hold down spring cup No.2 and parking brake shoe hold down spring pin No.2.

(b) Remove the parking brake shoe assy LH No.2.

(c) Using needle-nose pliers, disconnect the parking brake cable No.3 from the parking brake cable shoe lever.

NOTICE: Be careful not to damage parking brake cable No.3.

Supra Remove Rear Parking Brakes Calipers

10. SEPARATE SPEED SENSOR REAR LH (4WD DRIVE TYPE) (SEE PAGE 30-60 )

11. REMOVE REAR AXLE SHAFT LH NUT (4WD DRIVE TYPE) (SEE PAGE 30-60 )

SST 09930-00010

12. REMOVE REAR AXLE HUB & BEARING ASSY LH (4WD DRIVE TYPE) (SEE PAGE 30-60 )

13. REMOVE PARKING BRAKE SHOE HOLD DOWN SPRING PIN (4WD DRIVE TYPE)

(a) Remove the parking brake shoe hold down spring pin No.1.

14. REMOVE PARKING BRAKE SHOE TYPE C WASHER

(a) Using a screwdriver, remove the C-washer.

(b) Remove the shim and parking brake shoe lever from parking brake shoe assy LH No.2.

15. INSPECT PARKING BRAKE SHOE LINING THICKNESS

Supra Remove Rear Parking Brakes Rotors

(a) Using a ruler, measure the thickness of the shoe lining.

Standard thickness: 2.5 mm (0.098 in.) Minimum thickness: 1.0 mm (0.039 in.)

If the lining thickness is less than or equal to the minimum, or if there is severe or uneven wear, replace the brake shoe.

16. INSPECT BRAKE DISC AND PARKING BRAKE SHOE LINING FOR PROPER CONTACT

(a) Apply chalk to the inside surface of the disc, then grind down the brake shoe lining to fit disc.

If the contact between the brake disc and the shoe lining is improper, repair it using a brake shoe grinder or replace the brake shoe assembly.

17. INSTALL PARKING BRAKE SHOE TYPE C WASHER

(a) Using a feeler gauge, measure the clearance.

Standard clearance: Less than 0.35 mm (0.014 in.)

If the clearance is not within the specifications, replace the shim with one of the correct size.

(b) Using pliers, install the parking brake shoe lever LH and the shim with a new C-washer.

18. APPLY HIGH TEMPERATURE GREASE

(a) Apply high temperature grease to the shaded parts shown in the illustration of the backing plate which make contact with the shoe.

19. INSTALL PARKING BRAKE SHOE HOLD DOWN SPRING PIN (4WD DRIVE TYPE)

(a) Install the parking brake shoe hold down spring pin No.1.

20. INSTALL REAR AXLE HUB & BEARING ASSY LH (4WD DRIVE TYPE) (SEE PAGE 30-60 )

21. INSTALL REAR AXLE SHAFT LH NUT (4WD DRIVE TYPE) (SEE PAGE 30-60 )

22. INSTALL SPEED SENSOR REAR LH (4WD DRIVE TYPE) (SEE PAGE 30-60 )

23. INSTALL PARKING BRAKE SHOE ASSY LH NO.2

(a) Using needle-nose pliers, connect the parking brake cable No.3 to the parking brake cable shoe lever.

NOTICE: Be careful not to damage the parking brake cable No.3.

(b) Install the parking brake shoe assy LH No.2 with the parking brake shoe hold down spring, parking brake shoe hold down spring cup No.1, parking brake shoe hold down spring cup No.2 and parking brake shoe hold down spring pin No.2.

24. INSTALL PARKING BRAKE SHOE ADJUSTING SCREW SET

(a) Apply high temperature grease to the parking brake shoe adjusting bolt and piece.

(b) Attach the parking brake shoe return tension spring No.2 to parking brake shoe assy LH No.1 and parking brake shoe assy LH No.2.

(c) Attach the parking brake shoe adjusting screw set to the parking brake shoe assy LH No.1 and parking brake shoe assy LH No.2.

25. INSTALL PARKING BRAKE SHOE ASSY LH NO.1

(a) FF: Install the parking brake shoe hold down spring pin No.1.

(b) Install the parking brake shoe assy LH No.1 with the parking brake shoe hold down spring, parking brake shoe hold down spring cup No.2, parking brake shoe hold down spring cup No.2.

26. INSTALL PARKING BRAKE SHOE STRUT LH

(a) Attach the parking brake shoe strut LH and the parking brake shoe strut compression spring to parking brake shoe assy LH No.2 and parking brake shoe assy LH No.1.

27. INSTALL PARKING BRAKE SHOE RETURN TENSION SPRING

(a) Using needle-nose pliers, install the 2 return tension springs No.1 as shown in the illustration.

HINT: First install the front side spring then the rear side spring.

28. CHECK PARKING BRAKE INSTALLATION

(a) Check that each part is installed properly.

NOTICE: There should be no oil or grease on the friction surface of the shoe lining and disc

29. INSPECT BEARING BACKLASH (4WD DRIVE TYPE) (SEE PAGE 30-3 )

30. INSPECT AXLE HUB DEVIATION (4WD DRIVE TYPE) (SEE PAGE 30-3 )

31. INSTALL REAR DISC

(a) Aligning the matchmarks, install the rear disc.

32. ADJUST PARKING BRAKE SHOE CLEARANCE

(a) Temporarily install the hub nuts.

(b) Remove the hole plug, turn the adjuster and expand the shoes until the disc locks.

Toyota Supra Rear Differential

(c) Contract the shoe adjuster until the disc rotates smoothly.

Standard : Return 8 notches (d) Check that the shoe has no brake drag.

(e) Install the hole plug.

33. CONNECT REAR DISC BRAKE CALIPER ASSY LH

(a) Install the rear disc brake caliper assy LH with the 2 bolts.

Torque: 78 NVm (800 kgfVcm, 58 ftVlbf)

34. INSTALL REAR WHEEL

Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)

35. INSPECT PARKING BRAKE PEDAL TRAVEL (SEE PAGE 33-2 )

36. ADJUST PARKING BRAKE PEDAL TRAVEL (SEE PAGE 33-2 )

37. CHECK ABS SPEED SENSOR SIGNAL (4WD DRIVE TYPE) (SEE PAGE 05-765 )

More about Toyota Highlander:

Supra Rear Wheel Drive

Memory recall function
Each electronic key can be registered to recall your preferred driving position. Registering procedure Record your driving position to button “1” or “2” before performing the following: carry only the key you want to register, and then close the driver’s door. If 2 or more keys are in ...

How-To: Supra Subframe Swap

Supra Remove Rear Parking Brakes Master Cylinder

This swap will only work on a 1982-85 Celica that already has independent suspension. This swap will give your Celica an F series (7.5') differential and rear disc brakes. You should locate and remove the assembly from the donor car before beginning work on your car. Be sure to check the differential for signs of obvious ware and listen for any odd sounds. Now would be a good time for new (polyurethane) bushings, brake lines, CV boots and a brake system flush. You will almost certainly have to replace the rotors and it would be a good idea to replace or rebuild the calipers. You should also replace the differential side seals; they will leak soon if you don't.

If you want your speedometer to read accurately you will need to swap the speedometer gears. You may need just the driven gear, or you may need both the drive and driven gear. There are two numbers on the front of the driven gear. Lets say 10 and 31. 10 is how many teeth the drive gear has 31 is how many teeth this driven gear has. Compare these numbers to the driven gear from your transmission. If the smaller numbers are the same then just swap the driven gear in. But if the smaller numbers are different then you have to swap both the drive and driven gear.

To swap the drive gear on a manual you will have to remove the tail shaft from the transmission and pull the original drive gear off, then slide the new one on. This may be the same for automatics but I cannot say for sure as I haven't done this to an automatic.

Shopping List:

1. Rear Suspension Assembly from 1982-86 Toyota Supra

Tools Required:

Supra Rear End

1. Complete Metric Socket Set & Ratchet (1/2' drive)
2. Metric Open End Wrench Set
3. Breaker Bar (1/2' drive)
4. A strong friend or two to help you get it out of the junk yard [1]

Process:

1. Remove the rear wheels
2. Disconnect the parking brake cable from the handle (2 nuts) [2][3]
3. Pull the parking brake cable from the chassis clips [4]
4. Disconnect the driveshaft at the center carrier bearing [5]
5. Disconnect the rubber brake lines from the metal lines on the chassis
6. Disconnect the shock absorbers from the suspension arms
7. Release the fuel pump from the bracket on the differential carrier crossmember (If applicable) [6]
8. Disconnect the support plates from the chassis. [7]
9. Double check to make sure nothing is in the way. All pieces should be hanging free (driveshaft, parking brake cable, brake lines, fuel pump & lines)
10. Remove the nuts that retain the rear crossmember and the differential carrier crossmember (4 total) [8][9]
11. Remove the brake proportioning valve [10][11]
12. Installation is reverse of removal
13. Be sure to bleed the brakes very well
14. Check differential and brake fluid levels
15. Make sure the brake peddle has resistance an is functioning properly
16. After a short low speed drive check all bolts/nuts
17. Recheck all bolts/nuts after 10 miles, then 50 miles, then 100 miles. If the ever go slack, repeat

Footnotes:

1. The whole assembly weighs almost 300lbs. You WILL need help.
2. Be sure to pull the cable free under the chassis so it doesn’t get caught up when you drop the rear end.
3. You will need the parking brake cable for the disc brakes.
4. The clips are located in the sides of the driveshaft tunnel. About a foot back from the center bearing.
5. You will need the back half of the driveshaft.
6. Make sure the fuel pump will not get caught on anything when you drop the rear end.
7. The support plates are pieces of metal that go from the main crossmember nuts to the chassis. Only remove the smaller bolts that hold them to the chassis, not the main crossmember nuts
8. I would suggest starting with the right nut on the differential carrier because you will have your arm pined between the gas tank and rear end. Then move to the left bolt on the main crossmember, then the left bolt on the differential carrier crossmember, then the final bolt on the main crossmember.
9. Be VERY careful when you remove the final bolt. When the rear end drop with will go down with a big force and can easily break an arm. The rear end may not fall once the last bolt is removed. If it sticks DO NOT go under the car. Instead push down on the brakes until it drops. If it will not drop reinstall the 4 big nuts and then check for other connections.
10. The brake proportioning valve can be found behind the intake plenum of Celica's or on the driver side strut tower on Supra's.
11. You will a brake proportioning valve that matches the one you already have. Most Celica's use a 4-line valve while most Supra's use a 5-line valve. You can use the valve from any Celica with four-wheel disc brakes if it matches. You must have this piece or your new brakes will not function correctly.
