LT 1238 A Repair Parts Manual Ride Mower 954567024 For Husqvarna Parts Call 606-678-9623 or 606-561-4983 www.mymowerparts.com. 27 TRACTOR -MODEL NUMBER (LT1238) LT1238A, PRODUCT NO. 954 56 70-24 SCHEMATIC BATTERY FUSE IGNITION SWITCH RED RED RED BLACK IGNITION UNIT HEADLIGHTS REMOVABLE CONNECTIONS BLACK BLACK WHITE WHITE WHITE RED BLACK ORANGE. Mtd Lt 1238 Manual Mtd Lt 1238 Manual Your model number is required to find your owner's manual. To have an exact match, enter also a serial number. Select A Brand Bolens McCulloch MTD MTD Gold MTD Pro Yard-Man Ryobi Trimmer Plus White Outdoor Yard Machines Remington Page 4/25. Online Library Mtd Lt 1238 Manual Operators Manual - MTD Products. 13AP606G190 LT-1500 (2001) Page 2 of 19 Deck Assembly Ref # Part Number Qty S/P/F Description 1 16606 1 S Retainer Hook 2 618-0565 1 S Spindle Assembly, 5.75 Dia. 756-0980 1 Pulley Only 3 683-0198D 1 S 42-inch Deck Shell 4 683-0254 1 S Deck Adjustment Bracket w/ Weld Nut 5.
IPL, LT 1238 B, 954567024, 2001-03, Ride Mower, USA, Canada Can´t find what you are looking for? More documents can be found under Manuals and Downloads. Garden product manuals and free pdf instructions. Find the user manual you need for your lawn and garden product and more at ManualsOnline.
R1238A (1997) | Page 1 of 27 |
CHASSIS |
R1238A (1997) | Page 2 of 27 | ||
CHASSIS | |||
Ref # Part Number | Qty Description | ||
1 | 159530 | CHASSIS ASM | |
2 | 140356 | SUB= 145009 | |
3 | 17490612 | SCREW | |
4 | 19131216 | WASHER | |
5 | 155272 | BUMPER-HOOD/DASH | |
6 | 155924X010 | 'SADDLE FLAT,SLKSC' | |
8 | 155138 | CLIP.RETAINER | |
9 | 156272X010 | DASH SILKSCR | |
10 | 72140608 | SUB= 72110608 | |
11 | 155927 | 'PANEL-DASH,LH' | |
13 | 155934X010 | SUB= 169117X010 | |
14 | 17490608 | SCREW LT | |
15 | 74180512 | SCREW | |
16 | 73510500 | NUT | |
17 | 133956X505 | HOOD/GRILL ASM | |
18 | 126938X | SUB= 532126938 | |
24 | 74780616 | BOLT | |
25 | 19131312 | WASHER | |
26 | 73800600 | NUT | |
29 | 133954 | LENS SERVICE KIT | |
30 | 109872X505 | FENDER | |
31 | 136619 | BRKT FENDER | |
33 | 105476X505 | FOOTREST LH | |
34 | 105475X505 | FOOTREST RH | |
35 | 72110606 | BOLT | |
36 | 108067X | PAL NUT LT | |
38 | 139886 | BRACKET ASM LH | |
39 | 139887 | BRACKET ASM RH | |
45 | 132257 | SUB= 918132257 | |
46 | 127316X | RETAINER | |
71 | 73680400 | SUB= 73690400 | |
140 | 158418 | BRKT SUSPENSION | |
145 | 156524 | 'ROD POVOT,CHASSIS' | |
147 | 74760412 | BOLT LT | |
5479J | PLUG BUTTON T | ||
R1238A (1997) | Page 3 of 27 |
DECALS |
R1238A (1997) | Page 4 of 27 | ||
DECALS | |||
Ref # Part Number | Qty Description | ||
1 | 157106 | DECAL.INSTR.FRENC | |
2 | 132627 | GRILL DECAL | |
3 | 272440 | DECAL, HP ENGINE | |
4 | 129823 | NLA | |
5 | 157822 | 'DECAL INSERT,HOOD' | |
6 | 157140 | DECAL.CAUT.ENG/FR | |
7 | 101892X | DECAL T | |
8 | 132628 | FENDER DECAL | |
9 | 144465 | 'DECAL.CHASSIS.38'' | |
10 | 135013 | NLA | |
11 | 137259 | 'DECAL, WARNING' | |
12 | 141745 | DECAL HOOD RH RLY | |
13 | 127075 | 'DECAL,STR WHL' | |
14 | 141746 | DECAL HOOD LH RLY | |
15 | 145005 | DECAL.BATRY.3-3908 | |
16 | 140837 | DECAL BRAK PARK | |
17 | 136832 | DECAL | |
138311 | DECAL HANDLE LIFT | ||
158122 | MANUAL.O.CT12T38A | ||
159421 | MANUAL.P.R1238A | ||
LSB42 | SNOW THROWER | ||
LBD48 | SNOW BLADE | ||
LC05 | WHEEL WTS. | ||
CH12 | TIRE CHAINS | ||
MK380 | KIT.MULCHER | ||
C38 | GRASS CATCHER | ||
R1238A (1997) | Page 5 of 27 |
DRIVE |
R1238A (1997) | Page 6 of 27 | ||
DRIVE | |||
Ref # Part Number | Qty Description | ||
1 | 145598 | TRANSAXLE PEERLESS | |
2 | 146682 | SPRING.BRAKE.RETU | |
3 | 123666X | PULLEY TRANS | |
4 | 12000028 | SUB= 2267J | |
5 | 121520X | STRAP TORQUE | |
6 | 17490512 | SCREW | |
7 | 130802 | SUB= 162240 | |
8 | 131679 | SHIFT ROD | |
10 | 76020416 | PIN COTTER 1/8 | |
11 | 105701X | WASH-SHFT PLT LT | |
12 | 19151216 | WASHER | |
13 | 74550412 | BOLT.1/4-28.W/PAT | |
14 | 10040400 | LOCKWASHER | |
15 | 74490544 | BOLT.HX.FLG.5/16 | |
18 | 74780616 | BOLT | |
19 | 73800600 | NUT | |
21 | 106933X | KNOB T (1/2-HOLE) | |
22 | 130804 | BRAKE ROD | |
24 | 73350600 | NUT | |
25 | 106888X | SPRING ROD LT | |
26 | 19131316 | WASHER | |
27 | 76020412 | COTTER PIN | |
28 | 145204 | ROD.BRAKE.PARK.LT | |
29 | 71673 | PLUNGER CAP T | |
30 | 130807 | TRANSAXLE MTG BKT | |
31 | 127275X | 'KEEPER,BELT LH T' | |
32 | 74760512 | BOLT | |
34 | 155071 | SHAFT ASM-PEDAL F | |
35 | 120183X | NYLON BEARING | |
36 | 19211616 | WASHER LT | |
37 | 1572H | SUB= 2882J | |
38 | 123674X | PULLEY.IDLER.FLAT | |
39 | 74760644 | BOLT | |
40 | 4470J | SPACER T | |
41 | 154777 | SUB= 165692 | |
42 | 19131312 | WASHER | |
47 | 127783 | SUB= 139245 | |
48 | 154604 | BELLCRANK ASM | |
49 | 123205X | RETAIN BELT | |
50 | 74760624 | SUB= 74930624 | |
51 | 73680600 | SUB= 73690600 | |
52 | 73680500 | SUB= 73690500 | |
53 | 105710X | 'LINK, CLUTCH T' | |
54 | 2751R | CLIP T | |
55 | 105709X | 'SPRING, RETURN LT' | |
56 | 74760620 | SUB= 74780620 | |
57 | 130801 | SUB= 138255 | |
58 | 127274X | 'KEEPER,BELT RH T' | |
59 | 140312 | KEEPER BELT CNTSP | |
61 | 17490612 | SCREW | |
62 | 8883R | PEDAL COVER T | |
63 | 140186 | PULLEY.ENGINE | |
64 | 71170764 | BOLT | |
65 | 10040700 | LOCKWASHER | |
66 | 154778 | KEEPER-BELT | |
70 | 134683 | KEEPER BELT ENG | |
72 | 19132012 | WASHER | |
74 | 137057 | SPACER AXLE | |
R1238A (1997) | Page 7 of 27 | ||
DRIVE | |||
Ref # Part Number | Qty Description | ||
75 | 121749X | WASHER | |
76 | 12000001 | E-RING LT | |
77 | 123583X | SQUARE KEY | |
78 | 121748X | WASHER | |
79 | 2228M | SUB= 2228M1 | |
96 | 4497H | RETAINER M | |
112 | 19091210 | WASHER LT | |
113 | 127285X | 'STRAP,TORQUE' | |
116 | 72110610 | BOLT RDHD 3/8-16 | |
118 | 154774 | SPACER-BELLCRANK | |
121 | 154419 | NYLINER-CLUTCHING | |
Lt 1238 Manual User
R1238A (1997) | Page 8 of 27 |
ELECTRICAL |
R1238A (1997) | Page 9 of 27 | ||
ELECTRICAL | |||
Ref # Part Number | Qty Description | ||
1 | 144925 | SUB= 123899X | |
2 | 74760412 | BOLT LT | |
3 | 19091016 | WASHER | |
4 | 10040400 | LOCKWASHER | |
6 | 73220400 | SUB= 50675 | |
7 | 109238X | TUBE T | |
8 | 156417 | 'CASE,BATTERY.MECH' | |
9 | 109596X | HOSE CLAMP T | |
15 | 147688 | FASTNER.SNAP-IN | |
16 | 153664 | SWITCH INTERLOCK | |
19 | 10090400 | SUB= 10040400 | |
20 | 73350400 | NUT | |
21 | 136850 | 'HARNESS,LIGHT SOC' | |
22 | 4152J | HEADLAMP BULB | |
24 | 4799J | 'CABLE T, BATTERY' | |
25 | 146147 | CABLE.BTRY.6GA.RD | |
26 | 108824X | FUSE HYT | |
28 | 4207J | CABLE T | |
29 | 121305X | SWITCH SEAT | |
30 | 140301 | SWITCH IGN 4POS | |
31 | 124211X | NUT IGNITION | |
32 | 141226 | COVER KEY SWITCH | |
33 | 122147X | KEY | |
40 | 156442 | HARNESS-IGNITION | |
41 | 71110408 | BOLT HXHD FIN | |
42 | 131563 | SUB= 154336 | |
43 | 145673 | SUB= 146154 | |
44 | 73640400 | NUT HXKEP 1/4X20 | |
48 | 140844 | ADAPTER AMMETER | |
52 | 141940 | PROTECTION LOOP | |
70 | 140413 | HARNESS ENG DUAL | |
